Material | EPDM Foam with adhesive |
Adhesive | Backed with 3m double sided tape |
COLOR | Black |
Size | Any custom die cut shapes |
Thickness | 1mm-30mm |
feature | High adhesion, Fire retardant, heat resistant , waterproof |
Packaging | Cartons/plastic bags (customized) |
Applicable scope | As the part of protection/gluing/insulation/isolation in the area of electronic, furniture, machining, etc. |
EPDM Foam Date Sheet （below is for 18-25 shore c density, we also have other density) | ||||
Item | Unite | Reference Standard | Standard | Typical Value |
Size | mm | ASTM D3574 | 1000*2000*45 | 1000*2000*45 |
Tensile strength | kpa | ASTM D412 | >450 | 550 |
Hardness | shore c | JIS K6767 | 15±3 | 16 |
Density | Kg/m3 | ASTM D3574 | 140±20 | 142 |
Heat aging | % | ISO:2011 type B | ＜5 | 3.6 |
Elongation at break | % | ASTM D412 | > 150 | 160 |
Tear strength | KN/M | ASTM D624 | >2.0 | 2.5 |
Water absorption | % | ASTM D1056 | ＜5 | 3.9 |
25% Compression | kpa | ASTM D1056 | 55±20 | 49 |
Compression set | % | ASTM D395 | ＜40 | 33 |
